| SHRANK TAPER | ORDER CODE | ANGLE | M |
ØD (mm) |
ØD1 (mm) |
ØD2 (mm) |
ØD3 (mm) |
L (mm) |
L1 (mm) |
S (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| CAT-40 | RM-CAT40PS-5/8-11TPI | 45° | 5/8-11TPI | 17 | 22.5 | 10 | 14.9 | 57 | 33 | 19 |
| CAT-50 | RM-CAT50PS-1-8 | 45° | 1-8 | 25 | 28.9 | 17 | 22.9 | 77 | 44 | 30 |
