| SHRANK TAPER | ORDER CODE | DESCRIPTION | BORE |
L (mm) |
L 1 (mm) |
ØD (mm) |
|---|---|---|---|---|---|---|
| BT-30 | RM-BT30RS-25X1 | Reduction Socket with MT-1 | MT-1 | 48.4 | 45 | 25 |
| BT-30 | RM-BT30RS-32X1 | Reduction Socket with MT-2 | MT-2 | 48.4 | 60 | 32 |
| BT-30 | RM-BT30RS-40X1 | Reduction Socket with MT-3 | MT-3 | 48.4 | 75 | 40 |
| BT-30 | RM-BT30RS-48X1 | Reduction Socket with MT-4 | MT-4 | 48.4 | 95 | 48 |
| BT-40 | RM-BT40RS-25X1 | Reduction Socket with MT-1 | MT-1 | 65.4 | 45 | 25 |
| BT-40 | RM-BT40RS-32X1 | Reduction Socket with MT-2 | MT-2 | 65.4 | 60 | 32 |
| BT-40 | RM-BT40RS-40X1 | Reduction Socket with MT-3 | MT-3 | 65.4 | 75 | 40 |
| BT-40 | RM-BT40RS-48X1 | Reduction Socket with MT-4 | MT-4 | 65.4 | 95 | 48 |
| BT-50 | RM-BT50RS-25/45X1 | Reduction Socket with MT-1 | MT-1 | 101.8 | 45 | 25 |
| BT-50 | RM-BT50RS-25/120X1 | Reduction Socket with MT-1 | MT-1 | 101.8 | 120 | 25 |
| BT-50 | RM-BT50RS-32/45X1 | Reduction Socket with MT-2 | MT-2 | 101.8 | 45 | 32 |
| BT-50 | RM-BT50RS-32/135X1 | Reduction Socket with MT-2 | MT-2 | 101.8 | 135 | 32 |
| BT-50 | RM-BT50RS-40/60X1 | Reduction Socket with MT-3 | MT-3 | 101.8 | 60 | 40 |
| BT-50 | RM-BT50RS-40/155X1 | Reduction Socket with MT-3 | MT-3 | 101.8 | 155 | 40 |
| BT-50 | RM-BT50RS-48/85X1 | Reduction Socket with MT-4 | MT-4 | 101.8 | 85 | 48 |
| BT-50 | RM-BT50RS-48/180X1 | Reduction Socket with MT-4 | MT-4 | 101.8 | 180 | 48 |
| BT-50 | RM-BT50RS-48/100X1 | Reduction Socket with MT-5 | MT-5 | 101.8 | 100 | 48 |
| BT-50 | RM-BT50RS-48/220X1 | Reduction Socket with MT-5 | MT-5 | 101.8 | 220 | 48 |
